Fairino FR20
Fairino FR20
Massive 1854 mm reach for large-scale automation | 20 kg payload for heavy palletizing and logistics | Superior stability for high-speed, high-load cycles
Dominating the Workspace
The FR20 is the largest cobot in the Fairino family, boasting an incredible reach of 1854 mm. Combined with a 20 kg payload (max 25 kg), it is specifically designed to replace traditional industrial robots in large-scale palletizing, material handling, and wide-area welding.
High-Performance Throughput
With TCP speeds of up to 2 m/s, the FR20 is built for speed. It allows for rapid palletizing cycles, significantly increasing throughput in logistics and end-of-line packaging operations while maintaining a repeatability of ±0.1mm.
Industrial Scale, Collaborative Safety
At 105 kg, the FR20 provides the mass and stability needed for its impressive reach. Like its smaller siblings, it remains fully collaborative, featuring advanced safety systems that allow it to operate safely near humans, even when handling substantial loads.
Technical data
Applications for model
The applications listed below represent typical scenarios in which collaborative robots deliver long-term economic and technological value.
Advantages
Extended reach and dedicated software simplify the deployment of palletizing and sorting stations.
Maximized Range: Extended models like the FR20 provide up to 1854 mm of reach | Fast Setup: Palletizing software allows configuration in under 10 minutes without coding | Dynamic Picking: Real-time conveyor tracking picks items without stopping the line | Heavy Stacking: The FR30 model supports heavy-duty tasks with a 30 kg capacity
Limits
Throughput is affected by vertical reach constraints and collaborative safety protocols.
Height: Stacking is limited by the robot's vertical reach and may require lifting columns | Speed: In collaborative mode, safety sensors may slow down the robot when humans are present
Advantages
Open-source software and universal connectivity enable 24/7 integration with diverse industrial controllers.
Universal Talk: Native support for EtherCAT, Modbus, and Profinet protocols | 24/7 Operation: Enables "lights-out" manufacturing without human supervision | Mobile Ready: Lightweight MT and C variants are optimized for AGV or AMR mobile platforms | Rapid Changeover: Intuitive graphical programming allows for quick switching between workpieces
Limits
Heavy components and harsh cooling environments require specific hardware configurations.
Capacity: Handling is limited to the model payload, with a maximum of 30 kg | Sealing: Standard IP54 is insufficient for heavy coolant mist; IP65 or IP66 upgrades are required
